圖示1 Sketch1 |
圖示2 Sketch2 |
圖示3 Sketch3 |
型號
Model |
直徑 Ø 1 , Ø 2
Diameter (mm)
|
直徑 Ø 3
Diameter (mm)
|
長度 L
Length (mm) |
厚度 T
Thickness
|
圖示
Sketch
|
| WT45-0100-0100 |
100 |
100 |
341 |
1.0 |
可
依
顧
客
要
求
製
作
Customer's
request
|
圖示1
Sketch1
|
| WT45-0150-0150 |
150 |
150 |
412 |
1.0 |
| WT45-0200-0200 |
200 |
200 |
483 |
1.0 |
| WT45-0250-0250 |
250 |
250 |
554 |
1.0 |
| WT45-0300-0300 |
300 |
300 |
674 |
1.0 |
圖示2
Sketch2
|
| WT45-0350-0350 |
350 |
350 |
745 |
1.0 |
| WT45-0400-0400 |
400 |
400 |
816 |
1.0 |
| WT45-0450-0450 |
450 |
450 |
886 |
1.0 |
| WT45-0500-0500 |
500 |
500 |
957 |
1.0 |
| WT45-0550-0550 |
550 |
550 |
1028 |
1.0 |
| WT45-0600-0600 |
600 |
600 |
1098 |
1.0 |
| WT45-0700-0700 |
700 |
700 |
1240 |
1.0 |
| WT45-0800-0800 |
800 |
800 |
1381 |
1.0 |
| WT45-0900-0900 |
900 |
900 |
1523 |
1.0 |
| WT45-1000-1000 |
1000 |
1000 |
1664 |
1.2 |
| WT45-1100-1100 |
1100 |
1100 |
1805 |
1.2 |
| WT45-1200-1200 |
1200 |
1200 |
1947 |
1.2 |
| WT45-1300-1300 |
1300 |
1300 |
2088 |
1.2 |
| WT45-1400-1400 |
1400 |
1400 |
2230 |
1.2 |
| WT45-1500-1500 |
1500 |
1500 |
2371 |
1.5 |
| WT45-1600-1600 |
1600 |
1600 |
2562 |
1.5 |
圖示3
Sketch3
|
| WT45-1700-1700 |
1700 |
1700 |
2704 |
1.5 |
| WT45-1800-1800 |
1800 |
1800 |
2845 |
2.0 |
| WT45-1900-1900 |
1900 |
1900 |
2987 |
2.0 |
| WT45-2000-2000 |
2000 |
2000 |
3128 |
2.0 |
P.S. 風管直徑大於2000m/m以上,可由顧客指定製作
Duct diameter over 2000mm is available on request.
|
